One-to-One and Recursive relationship
Recursive relationship is a bit more complex and it won’t work on the website. To try queries in this section, we will use Workbench.
You can also run them in your Python program.
One-to-One Relationship
A one-to-one (1:1) relationship is a type of association between two entities where each instance of one entity is related to exactly one instance of the other, and vice versa. This setup is used when specific data is best organized across two tables to reduce redundancy or improve security. For example, in a database, a Person entity might have a one-to-one relationship with a Passport entity—each person has one unique passport, and each passport is assigned to only one person.
Modelling one-to-one relationship
Let’s consider this organizational chart. We can clarely see that each (one) department has a (one) head.
- 1:1 relationship is labeled
- A relationship descriptor
- Obvious relationships are not labeled
Querying One-to-One Relationship
GOOD NEWS! Querying one-to-one relationship works EXACTLY like the queries you already know :D .
We will use these new tables:
List the hotel name, first name and title of each hotel’s contact employee.
For reviews with a response, find the total number of reviews posted and their average response time in days for all reviews posted on Valentine’s day (2011-02-14). ((DATEDIFF(date2, date1) – calculates the difference between two dates)
Recursive Relationship
A recursive relationship occurs when an entity is related to itself. This happens when instances of the same entity type are connected in a hierarchical or referential way. For example, in an Employee entity, an employee might manage another employee, creating a recursive “manages” relationship within the same table. This is useful for modeling organizational charts, family trees, or any structure with self-referencing links.
Modelling recursive relationship
Let’s go back to our organizational chart. There is more here…
- A recursive relationship relates an entity to itself
- Label recursive relationships
Querying recursive relationship
A recursive relationship in a database, also known as a self-join, is when a table is joined with itself to represent relationships within the same entity. This technique is often used to model hierarchical or parent-child relationships, such as employees managing other employees. To perform a self-join, table aliasing is required so that the same table can be referenced multiple times in a query. For instance, using the alias boss in:
FROM employee AS boss
allows the query to distinguish between the employee acting as the manager and the one being managed. This approach is essential for querying and understanding internal relationships within a single table.
Open your Workbench and find the name of Leo Lee’s boss.
Handling NULL values
Don’t confuse with blank or zero
Multiple meanings: - Unknown data - Inapplicable data - No value supplied - Value undefined
NULL creates confusion because the user must make an inference
Try the following and observe the difference:
SELECT "a" IN ("a", "b", ""); SELECT "c" IN ("a", "b", ""); SELECT "" IN ("a", "b", ""); SELECT NULL IN ("a", "b", "");Handling NULL values in SQL requires special care, as they represent unknown or missing data.
Comparisons with NULL always return NULL, not TRUE or FALSE, which can lead to unexpected results. For example, NULL = NULL is not TRUE, but NULL, making the query:
SELECT * FROM hotel WHERE hotelRooms = NULL;incorrect.
Instead, the correct way to check for NULL values is with the IS NULL operator, like:
SELECT * FROM hotel WHERE hotelRooms IS NULL;Exercise
List the independent hotels (independent hotels are those properties not affiliated with any brand).
