Modelling Recap
Database modelling
Consider the following scenario. We will model his database step by step.
You are helping the head of an academic society (e.g., the Association for Information Systems) keep track of current data about members of the association (she does not care about historical data). She tells you that researchers are associated with one institution (university, research lab, etc.). Each researcher has one or more specific areas of research interests. Also, she tells you that she wants to know the team composition of research teams for teams funded by the Association. Team membership and collaboration is not mutually exclusive since academic research is best performed in teams and academics work on many projects at the same time.
In this text, we need to identify each phrase that gives us hints on what is expected in our database and design that element. For example, here is the first one:
You are helping the head of an academic society (e.g., the Association for Information Systems) keep track of current data about members of the association (she does not care about historical data). She tells you that researchers are associated with one institution (university, research lab, etc.). Each researcher has one or more specific areas of research interests. Also, she tells you that she wants to know the team composition of research teams for teams funded by the Association. Team membership and collaboration is not mutually exclusive since academic research is best performed in teams and academics work on many projects at the same time.
researchers are associated with one institution (university, research lab, etc.)
You are helping the head of an academic society (e.g., the Association for Information Systems) keep track of current data about members of the association (she does not care about historical data). She tells you that researchers are associated with one institution (university, research lab, etc.). Each researcher has one or more specific areas of research interests. Also, she tells you that she wants to know the team composition of research teams for teams funded by the Association. Team membership and collaboration is not mutually exclusive since academic research is best performed in teams and academics work on many projects at the same time.
Each researcher has one or more specific areas of research interests.
You are helping the head of an academic society (e.g., the Association for Information Systems) keep track of current data about members of the association (she does not care about historical data). She tells you that researchers are associated with one institution (university, research lab, etc.). Each researcher has one or more specific areas of research interests. Also, she tells you that she wants to know the team composition of research teams for teams funded by the Association. Team membership and collaboration is not mutually exclusive since academic research is best performed in teams and academics work on many projects at the same time.
the team composition of research teams for teams funded by the Association
You might be tempted to finish here, as your model already looks good. But let’s have a look at the scenario again. There is more info there.
You are helping the head of an academic society (e.g., the Association for Information Systems) keep track of current data about members of the association (she does not care about historical data). She tells you that researchers are associated with one institution (university, research lab, etc.). Each researcher has one or more specific areas of research interests. Also, she tells you that she wants to know the team composition of research teams for teams funded by the Association. Team membership and collaboration is not mutually exclusive since academic research is best performed in teams and academics work on many projects at the same time.
Team membership and collaboration is not mutually exclusive
Hints for Database modelling
The model will expand and contract
Invent identifiers where necessary
Identifiers should have only one purpose – identification
Single instance entities are OK
Label relationships to avoid ambiguity
Select names carefully
Synonyms—different words have the same meaning
- Get clients to settle on a common word or use views
Homonyms—same word has different meanings
- Clarify to avoid confusion
Naming associative entities
- Concatenate entity names if there is no obvious real world name
